GREASE LUBRICATION(PPE,190NNS,C9)T8
JAT710 / 810 · J-8505-QS20
Exploded Diagram — GREASE LUBRICATION(PPE,190NNS,C9)T8Drag to pan · Pinch/scroll to zoom · Double-click to reset
Parts List
10 items| Key | Part Number | Designation | Qty | Remarks | |
|---|---|---|---|---|---|
| 1 | J8143-15491-00 | LUBRICATOR-ASSY,LOOM(PPE,190NNS,C9) | 1 | — | |
| 2 | 81303-06030 | BOLT,HEXAGON 7T W/WASHER TYPE2 | 2 | — | |
| 3 | J8694-01020-00 | BRACKET,LUBRICATOR SURFACE ROLLER | 1 | — | |
| 4 | 84104-00600 | NUT,HEXAGON 7T W/PLATING | 1 | — | |
| 5 | 81303-06016 | BOLT,HEXAGON 7T W/WASHER TYPE2 | 2 | — | |
| 6 | 81303-06030 | BOLT,HEXAGON 7T W/WASHER TYPE2 | 2 | — | |
| 7 | 79111-06010 | BOLT,HEXAGON W/FLANGE | 2 | — | |
| 8 | 68600-00002 | BAND,T50R | 40 | — | |
| 9 | 68600-00003 | BAND,T50L | 10 | — | |
| 10 | 68630-09000 | CLAMP,M6 | 3 | — |
